| Stock-no. |
1120-412 |
| Categoria |
Planer-Type Milling M/C - Double Column |
| Fai |
NICOLAS CORREA |
| Tipo |
RAPID 50 |
| Anne |
2005 |
| Controllo |
CNC HEIDENHAIN TNC 530 HSCI |
| Luogo di stoccaggio |
Auf Anfrage |
| Paese di origine |
Spain |
| Tempi di consegna |
on inquiry |
| Quotazione |
Free carrier |
| Technische Dettagli |
| x-travel |
5.000 mm |
| y-travel |
3.100 mm |
| z-travel |
1.200 mm |
| Control |
HEIDENHAIN TNC 530 HSCI |
| table surface area |
5.000 x 2.000 mm |
| T-slots |
11 |
| T - slots - width |
22 mm |
| table weight |
30.000 Kg |
| rapid traverse X-axis |
20.000 mm/min |
| rapid motion - y-axis |
30.000 mm/min |
| number of spindle speeds |
6.000 U/min/rpm |
| Spindle power |
32 kW |
| taper ISO |
Kegel ISO 50 |
| Tools changer |
|
| distance between columns |
2.800 mm |
| Internal cooling system |
20 bar |
| total power requirement |
kW |
| weight of the machine ca. |
65 t |
| dimensions of the machine ca. |
15.100x6.200x6.250 mm |
| Descrizione |
Head UAD II positioning 0.1º / 0. 1º
Speed ranges 2
Tool clamping Hydraulic
Head 2 Vertical mandril
ATC positions 30
2 longitudinal chip conveyors
1 cross chip conveyor
Portable handwheel
Laser tool presetter
|
