Machining Center - Universal HERMLE C 40U DYNAMIC C 40 U DYNAMIC |
|
| Stock-no. |
1120-4033 |
| Categoria |
Machining Center - Universal |
| Fai |
HERMLE C 40U DYNAMIC |
| Tipo |
C 40 U DYNAMIC |
| Anne |
2006 |
| Controllo |
CNC HEIDENHAIN iTNC 530 |
| Luogo di stoccaggio |
Auf Anfrage |
| Paese di origine |
Germany |
| Tempi di consegna |
immediately |
| Quotazione |
Free carrier |
| Technische Dettagli |
| x-travel |
850 mm |
| y-travel |
700 mm |
| z-travel |
500 mm |
| Control |
HEIDENHAIN iTNC 530 |
| rotary table |
800 mm |
| c-axis |
0.001º ( ±360º) 0 |
| B-axis (table) |
+25 / -110 º mm |
| number of spindle speeds |
18.000 U/min/rpm |
| tool taper |
SK 40 DIN 69871 |
| spindle drive |
15 kW |
| max. torque on the spindle |
130 Nm |
| Tools changer |
38 fach/tools |
| Internal cooling system |
80 bar |
| handwheel |
HR- 410 |
| total power requirement |
41 kVA |
| weight of the machine ca. |
10,5 t |
| dimensions of the machine ca. |
m |
| Descrizione |
Equipment- Paper belt filter 200 l tank- Active control cabinet cooling-
Infrared probe M&H (Heidenhain)- Laser tool measuring system Blum- Chip
conveyor- Cleaning pistol with pump 2 bar / 40 l min- 3D Quick Set- Electronic
handwheel
|
|
|
|
